Container Dimension & Capacity

Date:

September 25, 19


20-Foot Standard Dry Cargo Container
Description Dimension & Capacity Steel
  External Dimensions Length 6,058mm (19'10"1/2)
Width 2,438mm (8'0")
Height 2,591mm (8'6")
  Internal Dimensions Length 5,899mm (19'4"1/4)
Width 2,352mm (7'9"9/16)
Height 2,386mm (7'9"15/16)
  Capacity Cubic Measurement 33.1m3 (1,169 cft)
Tare Weight 2,200 kgs (4,898 lbs)*
Payload 21,780 kgs (48,020 lbs)
Gross Weight 24,000 kgs (52,910 lbs)
  Door Openings Width 2,340mm (7'8"1/8)
Height 2,279mm (7'5")


_______________________________________________


40-Foot Standard Dry Cargo Container
Description Dimension & Capacity Steel
  External Dimensions Length 12,192mm (40'0")
Width 2,438mm (8'0")
Height 2,591mm (8'6")
  Internal Dimensions Length 12,033mm (39'5"3/4)
Width 2,352mm (7'8"5/8)
Height 2,386mm (7'9"15/16)
  Capacity Cubic Measurement 67.5m3 (2,385 cft)
Tare Weight 3,740 kgs (8,250 lbs)*
Payload 26,740 kgs (58,950 lbs)
Gross Weight 30,480 kgs (67,200 lbs)
  Door Openings Width 2,340mm (7'8"1/8)
Height 2,279mm (7'5"3/4)


_______________________________________________



40-Foot Hi-Cube Dry Cargo Container
Description Dimension & Capacity Steel
  External Dimensions Length 12,192mm (40'0")
Width 2,438mm (8'0")
Height 2,896mm (9'6")
  Internal Dimensions Length 12,033mm (39'5"3/4)
Width 2,352mm (7'8"5/8)
Height 2,691mm (8'9"15/16)
  Capacity Cubic Measurement 76.2cm3 (2,385 cft)
Tare Weight 3,920 kgs (8,640 lbs)*
Payload 26,560 kgs (58,560 lbs)
Gross Weight 30,480 kgs (67,200 lbs)
  Door Openings Width 2,340mm (7'8"1/8)
Height 2,577mm (8'5"1/2)


______________________________________________

20-Foot Refrigerated Container
Description Dimension & Capacity Steel
  External Dimensions Length 6,058mm (19'10"1/2)
Width 2,438mm (8'0")
Height 2,591mm (8'6")
  Internal Dimensions Length 5,486mm (18'0")
Width 2,270mm (7'5"3/8)
Height 2,234mm (7'3"15/16)
  Capacity Cubic Measurement 27.8m3 (982 cft)
Tare Weight 2,750 kgs (6,060 lbs)*
Payload 21,250 kgs (46,850 lbs)
Gross Weight 24,000 kgs (52,910 lbs)
  Door Openings Width 2,270mm (7'5"3/8)
Height 2,198mm (7'2"1/2)


_______________________________________________


40-Foot Hi-Cube Refrigerated Container
Description Dimension & Capacity Steel
  External Dimensions Length 12,192mm (40'0")
Width 2,438mm (8'0")
Height 2,896mm (9'6")
  Internal Dimensions Length 11,669mm (38'3"7/16)
Width 2,286mm (7'6")
Height 2,508mm (8'2"3/4)
  Capacity Cubic Measurement 66.9m3 (2,363 cft)
Tare Weight 4,600 kgs (10,140 lbs)*
Payload 25,880 kgs (57,060 lbs)
Gross Weight 30,480 kgs (67,200 lbs)
  Door Openings Width 2,286mm (7'6")
Height 2,437mm (7'11"15/16)

_______________________________________________


Flat Rack
  Length (m) Width (m) Height (m) Max. Payload (kg)
20'Flact Rack 5.92 2.43 2.26 31,000
40'Flact Rack 12 2.43 195 43,800

_______________________________________________


Open Top
  Length (m) Width (m) Height (m) Max. Payload (kg)
20'Open Top 5.89 2.35 2.35 28,100
40'Open Top 12 2.35 2.35 26,700
